Exit Device General Parts

• Mechanism Case & Parts

  • 661412, 25 Channel 3'
  • 661413, 25 Channel 4
  • 600305, 24 Channel Screw Pkg

• Center Case Kits & Parts

  • 650244, 25-C, CWDC Center Case Kit
  • 650259, (F)25-C/M Center Case Cover Kit
  • 600307, Center Case Cover Screw Pkg
  • 650261, 25-V/M/C Center Case Housing Kit
  • 600308, 25-V/M/C Center Case Housing Screw Pkg
  • 650263, 25-C Center Case Finger Kit
  • 600309, 25-V/C Finger Screw Pkg

• Push Bar kits & parts

  • 600319, 24/25 Pushbar Guide Pkg
  • 600310, 24/25 Pushbar Endcap Kit

• Cover Plate Kits & Parts

  • 650191, 25 Hex Dogging Kit 3'
  • 650192, 25 Hex Dogging Kit 4'
  • 650119, 25 Series CD Channel Cover Plate 3'
  • 650120, 25 Series CD Channel Cover Plate 4'
  • 090085 227 Dog Key 5/32", Package of 10
  • 650227, F-25 Channel Cover Plate 3'
  • 650228, F-25 Channel Cover Plate 4'

• End Cap Kit & Parts

  • 650294, 24/25 Channel Endcap Kit 1 3/4" Door
  • 650348, 24/25 Channel Endcap Kit 2 1/4" Door

• Mounting Pkg.

  • 650318, 24-C Mounting Pkg 1 3/4" Door
  • 650300, 24-C Mounting Pkg 2 1/4" Door
  • 650317, F-24-C Mounting Pkg 1 3/4" Door
  • 650346, F-24-C Mounting Pkg 2 1/4" Door

• Vertical Latches & Parts

  • 603, 25-C, C-WDC Top Latch Case
  • F603, F-24-C, C-WDC Top Latch Case
  • 650339, (F)24-C, CWDC Top Latch Release Kit
  • 4567, 24-C Bottom Bolt Guide
  • 650376, (F)24-C, CWDC Center Slide Assembly

• Vertical Rods & Parts

  • 610061, (F)24-C, CWDC Top Rod Kit
  • 610057, (F)24-C, CWDC Bottom Rod Kit
  • 660002, #10 x 1 1/4" FPHSMS
  • 650017, Concealed Vertical Extension Rod 12"
  • 650018, Concealed Vertical Extension Rod 24"
  • 650019, Concealed Vertical Extension Rod 36"

Exit Device Mechanical Options Parts

• CD - Cylinder dogging

  • 650159, 25 Series Cylinder Dogging (CD) Kit 3'
  • 650160, 25 Series Cylinder Dogging (CD) Kit 4'

Exit Device Electrified Options Parts

• Switch Kits & Parts

  • 650359, 24/25 Series RX Switch Kit

• MEL - Motorized Electric Latch Retraction Kit & Parts

  • 47266630 Motorized Latch Retraction Kit for 36" 25 Series Exit Devices
  • 47266631 Motorized Latch Retraction Kit for 48" 25 Series Exit Devices
  • 114320, QEL Motor Cable
  • 47269206, QEL/MEL Motor Cable with 6' Harness
  • 106198, QEL CON Adapter Harness
  • 040069, QEL Motor Cable w/ QEL CON Adapter Harness

• Misc. parts/Kits

  • 050534 EL Potted Circuit Breaker
  • 106182, ALK CON Adapter Harness
  • 060111, 1/8" x 1" Cotter Key package of 10

• EA - Exit Alarm

  • 650167, 25 Series Exit Alarm (EA) Kit 3'
  • 650168, 25 Series Exit Alarm (EA) Kit 4'

Exit Device Accessories & Parts

• Strikes

  • 264 Top Strike, Optional Panic Strike
  • 299 Rim/Vertical Rod Top Strike
  • 299F Rim/Vertical Rod Top Strike, Fire Rated
  • 499F Rim/Vertical Rod Top Strike, for 22/75/78/98/99 w/9954 Mullion - Standard
  • 1439, US19 Rim Strike, Standard 33A/35A/75 Panic Strike, Optional 22 Strike
  • 1606 Rim Strike, Optional Strike For 1654 Mullion, Panic Single or Paired
  • 1609 Rim Strike, Optional Panic Strike

• Cylinders

  • 985, 1-1/8" Mortise Cylinder, Falcon MA Cam (5622-STD (F1)), 6-Pin G Keyway, Keyed Different, 2 Cut Keys
  • 986, 1-1/4" Mortise Cylinder, Falcon MA Cam (5622-STD (F1)), 6-Pin G Keyway, Keyed Different, 2 Cut Keys
  • 951, Rim Cylinder

• Shim Kits

  • 650108, 25 Surface Vertical Device Shim Kit 1/4", > 7' up to 8' Door
  • 650266, 25 Surface Vertical Device Shim Kit 1/4", > 8' up to 10' Door
