General Exit Device Parts

• Mechanism Case & Parts

  • 661408, 24 Channel 3'
  • 661409, 24 Channel 4'
  • 600305, 24 Channel Screw Pkg

• Push Bar kits & parts

  • 600319, 24/25 Pushbar Guide Pkg
  • 600310, 24/25 Pushbar Endcap Kit

• Cover Plate Kits & Parts

  • 650121, F-24 Channel Cover 3'
  • 650122, F-24 Channel Cover 4'
  • 650117, 24 Series CD Channel Cover Plate 3'
  • 650116, 24 Series CD Channel Cover Plate 4'
  • 650187, 24 Hex Dogging Kit 3'
  • 650188, 24 Hex Dogging Kit 4'
  • 090085 227 Dog Key 5/32", Package of 10
  • 650139, 24 Series KOR Channel Cover Plate 3'
  • 650140, 24 Series KOR Channel Cover Plate 4'

• Center Case Kits & Parts

  • 650236, (F)24-V Center Case Kit
  • 650251, (F)24-V Center Case Cover Kit
  • 600307, Center Case Cover Screw Pkg

• End Cap Kit & Parts

  • 650294, 24/25 Channel Endcap Kit 1 3/4" Door
  • 650348, 24/25 Channel Endcap Kit 2 1/4" Door

• Mounting Pkg.

  • 650304, 24-V Mounting Pkg 1 3/4" - 2 1/4" Door
  • 650325, F-24-V Mounting Pkg 1 3/4" Door
  • 650201, F-24-V Mounting Pkg 2 1/4" Door
  • 650327, F-24-CWDC 90 Minute Mounting Pkg 1 3/4" Door

• Vertical Latches & Parts

  • 650389, 19-V Top Latch Case
  • 650375, 24-V Top Latch Case - Fire
  • 650202, 24-V Latch Case Cover
  • 650336, 24-V Latch Case Cover Screw Pkg
  • 650387, Bottom Bolt Guide (screws not included)

• Vertical Rods

  • 650311, 24-V Rod Guide Kit
  • 4450, 24-V Top Rod Kit
  • 610056, 24-V Bottom Bolt Kit
  • 660002, #10 x 1 1/4" FPHSMS

Mechanical Options Parts

• CD - Cylinder dogging

  • 650155, 24 Series Cylinder Dogging (CD) Kit 3'
  • 650156, 24 Series Cylinder Dogging (CD) Kit 4'

Electrified Options Parts

• Switch Kits & Parts

  • 650359, 24/25 Series RX Switch Kit

• MEL - Motorized Electric Latch Retraction Kit & Parts

  • 47266632 Motorized Latch Retraction Kit for 36" 24 Series Exit Devices
  • 47266633 Motorized Latch Retraction Kit for 48" 24 Series Exit Devices
  • 114320, QEL Motor Cable
  • 47269206, QEL/MEL Motor Cable with 6' Harness
  • 106198, QEL CON Adapter Harness
  • 040069, QEL Motor Cable w/ QEL CON Adapter Harness

• Misc. parts/Kits

  • 050534 EL Potted Circuit Breaker
  • 060111, 1/8" x 1" Cotter Key package of 10

• EA - Exit Alarm

  • 650163, 24 Series Exit Alarm (EA) Kit 3'
  • 650164, 24 Series Exit Alarm (EA) Kit 4'

Exit Device Accessories & Parts

• Strikes

  • 3788, Vertical Rod Top Strike
  • 2130, Vertical Rod Bottom Strike

• Cylinders

  • 985, 1-1/8" Mortise Cylinder, Falcon MA Cam (5622-STD (F1)), 6-Pin G Keyway, Keyed Different, 2 Cut Keys
  • 986, 1-1/4" Mortise Cylinder, Falcon MA Cam (5622-STD (F1)), 6-Pin G Keyway, Keyed Different, 2 Cut Keys
  • 951, Rim Cylinder

• Shim Kits

  • 650110, 24 Surface Vertical Device Shim Kit 1/4", > 7' up to 8' Door
  • 650208, 24 Surface Vertical Device Shim Kit 1/4", > 8' up to 10' Door

• Extension Rods

  • 650006, 19/24/25/XX-V Extension Rod 12"
  • 650007, 19/24/25/XX-V Extension Rod 24"
  • 650008, 19/24/25/XX-V Extension Rod 36"
