The Schlage 47-413 is the OEM 6-pin conventional cylinder for the Schlage Portable Security KS Series padlock, documented in the Schlage Key Systems Cylinders and Keys Catalog (doc 109487). The cylinder ships Keyed Different (KD) with two brass keys, is non-handed, and is available in 27 keyway configurations spanning the Schlage Classic open keyway family, bi-sectional keyways, Everest 29 C restricted keyways, and Everest 29 S restricted keyways. Finish must be specified at time of order. In stock.

"Keyed Different" means each 47-413 cylinder ordered receives its own unique bitting - no two KD cylinders in the same order will operate on the same key. If padlocks need to share one key (keyed alike) or integrate into a master key system, specify KA or MK at order time.

Why 27 Keyways on a Schlage Padlock Cylinder

The most common reason to order the 47-413 is key system unification. A commercial facility, campus, or institution using Schlage cylindrical or mortise locks on their internal doors can specify the same keyway on the 47-413 padlock cylinder as on the rest of the hardware. The maintenance supervisor's key ring operates padlocks and interior doors without carrying separate padlock keys.

The 27 keyway options cover every level of key control available in the Schlage key system family:

Classic open keyways (C, E, F, G): Unrestricted keyways available from any authorized Schlage dealer. No ordering formalities required. Standard security for facilities where key duplication at a locksmith is acceptable. Bi-sectional options (CE, EF, FG) combine two keyway profiles for a modest improvement in key differentiation without entering the restricted keyway program.

Everest 29 C restricted keyways (C123 through C345): The Everest 29 C family is a restricted keyway - blanks are only available through authorized Allegion distribution with verifiable factory authorization. These keyways prevent unauthorized key duplication at hardware stores and most locksmiths. Facilities that want physical key control on padlocks order C-series Everest keyways to match their existing Everest-keyed door hardware.

Everest 29 S restricted keyways (S123 through S345): The S keyway family adds a check pin inside the cylinder, per the official Schlage commercial website. The check pin means a C-family key cannot accidentally operate an S-family lock even if the bitting profile is otherwise similar. This is the additional security layer for facilities that want geographic key exclusivity plus mechanical key differentiation between door zones. The S keyway is particularly useful for facilities that have both Everest C-keyed doors and S-keyed padlocks - the two systems cannot cross-operate.

Schlage 47-413: What the 6-Pin Conventional Cylinder Provides

The 47-413 is a 6-pin conventional cylinder, as opposed to a 5-pin or interchangeable core format. Six pins provide more keying combinations than five pins, which matters in large master key systems where each padlock in a building needs a unique change key while still operating on common master keys. A 6-pin system supports a significantly larger key matrix without key conflicts.

Conventional format means the cylinder plug and shell are a fixed unit - not removable like an IC (interchangeable core) cylinder. Rekeying a conventional padlock cylinder requires removing and repinning the cylinder or replacing it with a new 47-413 cut to the desired bitting. The cylinder ships with two brass keys already cut, so it is ready to use upon arrival without additional key cutting.

Schlage Conventional Padlock Parts: KS Series Application

The 47-413 is specified for the Schlage Portable Security KS Series padlocks, confirmed in the Schlage Key Systems Cylinders and Keys Catalog. KS Series padlocks are used in chain-link fence and gate applications, utility meter enclosures, mechanical equipment rooms, storage unit hardware, and industrial lockout/tagout stations where a heavy-duty commercial padlock body is required.

The 47-413 allows a worn or lost cylinder in an existing KS Series padlock body to be replaced without purchasing a complete new padlock, which is the standard field service path when the padlock body is intact but the cylinder needs replacement or rekeying for a new tenant or occupant.

SecurityParts stocks OEM Schlage padlock cylinders and key system components. Free shipping on orders over $450.
