Schlage L483-007 Chassis Harness with RX Module Switch

Schlage L483-007 Chassis Harness with RX Module Switch Packaging

Schlage

SKU: L483-007

Schlage L483-007 Chassis Harness with RX Module Switch

In stock

The Schlage L483-007 Chassis Harness with RX Module Switch is an OEM replacement wiring harness assembly for Schlage LE Series electronic mortise locks.

The Schlage L483-007 Chassis Harness with RX Module Switch is a genuine OEM replacement part designed for Schlage LE Series electronic mortise locks. This replacement harness integrates the Request-to-Exit (RX) module switch into the chassis wiring assembly, allowing proper communication of the RX function within the lock. It is intended as a direct replacement for damaged or malfunctioning chassis harnesses equipped with an RX module switch.

We are your trusted source for commercial door hardware, electronic access control products, and OEM replacement parts.

Manufacturer: Schlage
Part Number: L483-007
Product Type: Chassis Harness with RX Module Switch
Product Series: LE Series
Primary Function: Replacement chassis wiring harness with integrated Request-to-Exit (RX) module switch
Application: LE Series electronic mortise locks
OEM Part: Yes

$169.00
$152.10
minus minus

Price Books

Frequently Asked Questions

What is the Schlage L483-007?
It is an OEM chassis harness with an integrated Request-to-Exit (RX) module switch for Schlage LE Series electronic mortise locks.
What does the RX module switch do?
The RX module switch provides the Request-to-Exit (RX) signaling function used by compatible access control systems.
Can this be used to repair a damaged RX harness?
Yes. It is intended as the OEM replacement harness assembly for the RX module switch.
Which lock series uses the L483-007?
It is designed for Schlage LE Series electronic mortise locks
Is this an OEM Schlage replacement part?
Yes. It is a genuine Schlage OEM replacement part.
