Schlage MT11-485 is a mullion-mount multi-technology reader that provides credential reading for commercial electronic access control systems. It supports 125 kHz proximity and 13.56 MHz smart credential technologies and uses RS-485 communication with OSDP support. The reader is designed for interior and exterior applications and provides LED and audio feedback during credential interaction.

We are your trusted source for commercial door hardware, electronic access control products, and OEM replacement parts.

Manufacturer: Schlage
Part Number: MTB11-485
Product Type: Multi-Technology Mullion Reader
Mounting Style: Mullion
Supported Technologies:

• Bluetooth Low Energy (BLE)
• Wallet-Based NFC
• 13.56 MHz smart
• 125 kHz proximity

System Interface:

• RS-485 capability
• Open Supervised Device Protocol (OSDP)
• Wiegand

Power: 5–16 VDC
Dimensions: 5.91" H × 1.72" W × 0.81" D
Material: PBT Polymer
Standards: ISO 14443A, ISO 14443B, ISO 15693
Visual Indicator: Red, green, or amber LED
Primary Function: Electronic access control credential
Application: Commercial electronic access control and credential authentication
OEM Part: Yes

• Lifetime — Smart Readers & Digital Credentials: Schlage commercial multi-technology smart readers, proximity readers, intelligent credentials, smart cards, key fobs, and mobile access hardware carry a limited lifetime warranty against manufacturing defects for the original user.
• 3 Years — High-Security Smart Locks & Commercial Hardware: Schlage commercial electrified cylindrical and mortise locks, electronic trim packages, and electrified emergency exit lock trims carry a 3-year warranty from the date of factory shipment.
• 3 Years — Power Supplies & System Controllers: Schlage electronics power supplies, integrated power controllers, option boards, and heavy-duty system logic controllers carry a 3-year warranty from the date of manufacture.
• 3 Years — Premium Connected Home & Smart Locks: Schlage premium residential smart locks and connected home devices carry a 3-year limited electronics warranty from the original retail date of purchase.
• 1 Year — Electronic Keypad Locks & Installation Adapters: Schlage digital electronic keypad deadbolts, lever locks, quick-connect installation accessories, electronic pigtail converters, and adapter cables carry a 1-year limited electronics warranty.
