Cylindrical Locks General Parts

• Chassis assembly & Parts

  • A30765-000-00 T-Series T291/301 Chassis Assy, Non-Keyed
  • 030726-000-30, T Series Flanged Nut
  • 030712-001-30, Mounting plate, outer
  • 031533-006-30, Self-tap screw
  • A30746-000-00, Hub and housing assembly
  • 030733-000-55, T Series Inner Spindle
  • 022106-002-55, RU Series Retractor
  • 022986-001-50, RU Series Retractor Insert
  • 022108-000-60, RU Series Retractor Spring
  • 022112-000-30, Retainer, retractor spring
  • A30747-000-00, T Series Hub Assembly
  • 030712-000-30, T Series Mounting Plate
  • 030709-000-60, T Series Clutch Spring
  • 030718-000-30, T Series Key Spindle Assembly
  • 022105-000-30, Slide catch
  • 030722-000-30, Dogging bar
  • 030728-000, Push button cap

• Trim assembly Parts

  • 030724-000-30, Lever retaining ring
  • 030831-004-30, Set screw for standard lever
  • A30753-01A, T Series Inside Open Lever, w/Set Screw, Avalon
  • 030706-002 T Series Rose
  • 23981137, Spring latch, standard
  • 024416-012, Latch and Strike screws
  • 030703-000-30, T/RU Series Inner Spindle
  • 030787-000-70, Button spacer
  • 030654-000-625, Emergency release cap
  • 030654-000-626, Emergency release cap
  • 030729-000-70, Outer button mount
  • 030739-000-30, SFIC Cylinder Tailpiece, T/R Series 6-Pin
  • Q330-271, T Series Spring Cage Kit

• Levers

  • 030740-001 T Series Open Avalon Lever
  • A30753-01A, T Series Inside Open Lever, w/Set Screw, Avalon
  • Q330-431-BRK Boardwalk lever, open
  • A30753-01-BRK, T Series Inside Open Lever, w/Set Screw, Boardwalk
  • Q330-431-BRW T-Series Lever - Broadway, Open - Exterior
  • A30753-01-BRW, T Series Inside Open Lever, w/Set Screw, Broadway
  • 030742-001 T Series Open Dane Lever
  • A30753-01D, T Series Inside Open Lever, w/Set Screw, Dane
  • Q330-431-LAT T-Series Lever - Latitude, Open - Exterior
  • A30753-01LAT, T Series Inside Open Lever, w/Set Screw, Latitude
  • Q330-431-LON Longitude lever, open
  • A30753-01-LON, T Series Inside Open Lever, w/Set Screw, Longitude
  • 030744-001 T Series Open Quantum Lever
  • A30753-01Q, T Series Inside Open Lever, w/Set Screw, Quantum

• Latch

  • 23981137, Spring latch, standard
  • 23981111, T Series 2-3/8" Springlatch
  • 24074387, Spring latch

• Roses

  • 030706-002 T Series Rose

• Strikes t

  • 005164-000, ANSI Strike
  • A05185-000, Standard T-Strike
  • A05185-004, Radius T-Strike
  • Q001-048, B / T Series Full Lip Strike 1-5/8
  • Q001-049, B / T Series Full Lip Strike 1-5/8
  • 005161-000, ANSI, 7/8” lip length
  • 005099-000-30 ANSI Dust Box, 1" Deep, Steel

• Screws

  • 021164-016, ANSI Strike Screw
  • 024416-012, Latch and Strike screws
  • 030755-005-30, Type D screw
  • 030831-004-30, Set screw for standard lever
  • 031515-004-30, Fillister Head screw
  • 031533-006-30, Self-tap screw
  • 002770-016-30, T/RU Series Insert Screw
